Zawór SIE311

Name: Zawór SIE311
Brand: YPC
SKU: YPC-SIE311-IP
Price: 81.76 EUR

Dostępny Wysyłka: 1-2 dni robocze

EUR 81.76 EUR 66.47

SKU

YPC-SIE311-IP

Dostępność Duże stany magazynowe

Wsparcie techniczne Pomożemy dobrać rozwiązanie

Dokumentacja Karty katalogowe i certyfikaty

Szybka wysyłka Zamów dziś, wyślemy jutro

Zawór SIE311

function 5/2 monostable

max. pressure [bar]. 10

pressure range (two numbers separated by a dash in bar) [bar] 1.5 - 10

nominal flow at 7 bar [l/min] 1000

medium compressed air, inert gases

temperature range (two numbers with hyphen) [°C] 5 - 60

Dane techniczne:

Budowa:

Dane techniczne

More Information
SKU	YPC-SIE311-IP
Producent	YPC
dimensions (width) [mm].	26
function	5/2 monostable
design size	ISO-0 26 mm
return method	air + spring
nominal flow at 7 bar [l/min]	1000
pressure range (two numbers separated by a dash in bar) [bar]	1.5 - 10
temperature range (two numbers with hyphen) [°C]	5 - 60
max. pressure [bar].	10
medium	compressed air, inert gases
type of control	internal remote control
manual override	button
response time (5 bar) [ms].	25
operating frequency [Hz].	5

Download dimensions

More Information
SKU	YPC-SIE311-IP
Producent	YPC
dimensions (width) [mm].	26
function	5/2 monostable
design size	ISO-0 26 mm
return method	air + spring
nominal flow at 7 bar [l/min]	1000
pressure range (two numbers separated by a dash in bar) [bar]	1.5 - 10
temperature range (two numbers with hyphen) [°C]	5 - 60
max. pressure [bar].	10
medium	compressed air, inert gases
type of control	internal remote control
manual override	button
response time (5 bar) [ms].	25
operating frequency [Hz].	5

Download dimensions
