- Piston diameter: 6 mm
- Actuator stroke: 15 mm
- Thread on the piston rod: M3
- Operation: one-sided with front spring
- Medium: filtered air (50 µ)
- Working pressure: 2-7 bar
- Maximum temperature: + 60 ° C
- Pressing force [6 bar]: 12 N
- Spring return force: 1.2 N [stroke 0]; 3.8 N [end of stroke]
- Weight: 15 g
| SKU | C-K-006-0015M |
|---|---|
| Producent | Janatics |
| piston diameter [mm] | 6 |
| stroke of actuator [mm] | 15 |
| action | spring return |
| pressure range (two numbers separated by a dash in bar) [bar] | 2 - 7 |
| temperature range (two numbers with hyphen) [°C] | -10 - 70 |
| body | nickel-plated brass |
| piston rod | stainless steel AISI 303 |
| seals | polyurethane |
| spring | steel |
