Single acting pneumatic cylinder 016 X 010 S
- Connection: M5
- Piston diameter: 16 mm
- Actuator stroke: 10 mm
- Action: spring return
- kompaktowa budowa
- wysoka wydajność przepływu
- szeroki zakres ciśnień
- niezawodna praca w automatyce przemysłowej
Pneumatig
SKU: C-M-016-0010S
Single acting pneumatic cylinder 016 X 010 S
Dostępny Wysyłka: 1-2 dni robocze
EUR 46.26 EUR 37.61
SKU
C-M-016-0010S
Dostępność Duże stany magazynowe
Wsparcie techniczne Pomożemy dobrać rozwiązanie
Dokumentacja Karty katalogowe i certyfikaty
Szybka wysyłka Zamów dziś, wyślemy jutro
Pneumatic cylinder 016 X 010 with spring return
connection M5
pressure range (two numbers separated by a dash in bar) [bar] 1 - 10
temperature range (two numbers with hyphen) [°C] -10 - 70
stroke of actuator [mm] 10
piston diameter [mm] 16
action spring return
Dane techniczne
| SKU | C-M-016-0010S |
|---|---|
| Producent | Pneumatig |
| piston diameter [mm] | 16 |
| stroke of actuator [mm] | 10 |
| connection | M5 |
| action | spring return |
| pressure range (two numbers separated by a dash in bar) [bar] | 1 - 10 |
| temperature range (two numbers with hyphen) [°C] | -10 - 70 |
| body | stainless steel |
| covers | anodized aluminium |
| piston rod | stainless steel AISI 303 |
| seals | polyurethane + NBR |
| amortization | mechanical |
| spring | steel |
Download
| SKU | C-M-016-0010S |
|---|---|
| Producent | Pneumatig |
| piston diameter [mm] | 16 |
| stroke of actuator [mm] | 10 |
| connection | M5 |
| action | spring return |
| pressure range (two numbers separated by a dash in bar) [bar] | 1 - 10 |
| temperature range (two numbers with hyphen) [°C] | -10 - 70 |
| body | stainless steel |
| covers | anodized aluminium |
| piston rod | stainless steel AISI 303 |
| seals | polyurethane + NBR |
| amortization | mechanical |
| spring | steel |
