SAMH550 Activated charcoal filter 1 ″

Name: SAMH550 Activated charcoal filter 1 ″
Brand: Hi-Tech
SKU: AGD-SAMH550
Price: 232.32 EUR

Dostępny Wysyłka: 1-2 dni robocze

EUR 232.32 EUR 188.88

SKU

AGD-SAMH550

Dostępność Duże stany magazynowe

Wsparcie techniczne Pomożemy dobrać rozwiązanie

Dokumentacja Karty katalogowe i certyfikaty

Szybka wysyłka Zamów dziś, wyślemy jutro

SAMH550 Activated carbon filter 1 "

connection G 1″

max. pressure [bar]. 15

pressure range (two numbers separated by a dash in bar) [bar] 1.5 - 10

nominal flow at 7 bar [l/min] 5000

medium compressed air

temperature range (two numbers with hyphen) [°C] 5 - 60

The filter is equipped with an automatic condensate drain

Dane techniczne

More Information
SKU	AGD-SAMH550
Producent	Hi-Tech
dimensions (width) [mm].	130
dimensions (height) [mm]	318
connection	G 1″
nominal flow at 7 bar [l/min]	5000
filtration [µm]	0,01
temperature range (two numbers with hyphen) [°C]	5 - 60
pressure range (two numbers separated by a dash in bar) [bar]	1.5 - 10
max. pressure [bar].	15
medium	compressed air
equipment	automatic condensate drain

Download dimensions

More Information
SKU	AGD-SAMH550
Producent	Hi-Tech
dimensions (width) [mm].	130
dimensions (height) [mm]	318
connection	G 1″
nominal flow at 7 bar [l/min]	5000
filtration [µm]	0,01
temperature range (two numbers with hyphen) [°C]	5 - 60
pressure range (two numbers separated by a dash in bar) [bar]	1.5 - 10
max. pressure [bar].	15
medium	compressed air
equipment	automatic condensate drain

Download dimensions
