Screw compressor Atlas Copco GA 11 VSD WORKPLACE FF
Atlas Copco GA 11 VSD WorkPlace Full Feature screw compressor with variable speed.
Oil-injected screw compressor, air-cooled, belt-driven, in a soundproof housing, equipped with an inverter for the electric motor, controlled by an advanced Elektronikon microcontroller.
Full Feature version - with a built-in refrigerant dryer (optionally, it is possible to install a bypass for the dryer and the installation of compressed air filters of class I or II according to ISO 8573-1).
Savings thanks to VSD technology can reach up to 35% of electricity consumption
- Tank: 270l
- Capacity (FAD) at 5.5 bar: 396 - 1860 l / min
- Capacity (FAD) at 7.5 bar: 390 - 1842 l / min
- Capacity (FAD) at 10 bar: 522 - 1446 l / min
- Capacity (FAD) at 13 bar: 474 - 1242 l / min
- Working pressure range: from 4 to 13 bar
- Engine power: 11 kW
- Voltage: 400V
- Noise level: 66 dB
- Dimensions: length 1498 mm. x width 699 mm. x height 1729 mm.
- Weight: 403 kg
- Full Feature version; with integrated CPR refrigerant dryer. + 3 ° C,
- built-in OSD condensate separator,
- Optionally built-in compressed air filters class I or II according to ISO 8573-1,
- Optional built-in bypass for refrigerant dryer,
- connection to the AIR Connect system (remote supervision of the compressor / group of compressors,
- and many other elements of equipment at the customer's request
|integrated tank||270 Büchstaben|
|voltage (table) [V].||400|
|motor power [kW].||11|
|noise level (table) [dB].||66|
